LoRa SX1276 SX1278 868MHz 1W Long Range 8000m Wireless Transmitter and Receiver RF Module EBYTE E32-868T30S SMD Stamp Hole
17.96$
LoRa SX1276 SX1278 868MHz 1W Long Range 8000m Wireless Transmitter and Receiver RF Module EBYTE E32-868T30S SMD Stamp Hole
| RF Parameter | Value | Remark |
| Working frequency | 862~893 MHz |
Default: 868MHz |
| Transmitting power | 21~30 dBm |
Default: 30dBm(About 1W) |
| Receiving sensitivity | -147 dBm |
Air data rate: 0.3kbps |
| Air data rate | 0.3k~19.2kbps |
Default: 2.4kbps |
| Test distance | 8000 meter |
In open and clear air, with maximum power, 5dBi antenna gain, height of 2m, air data rate: 2.4kbps |
| Hardware Parameter | Value | Remark |
| Size | 25 * 40.3 mm | |
| Antenna type | IPX/Stamp hole | |
| Communication interface | UART |
Baud rate: 1200~115200, default: 9600 |
| Package | SMD | |
| Buffer | 512 bytes buffer |
Automatically sub-packaging with 58 bytes per package |
| Electronic parameter | Min. | Typ. | Max. | Unit | Condition |
| Power supply | 3.3 | 5.0 | 5.2 | V | |
| Communication level | 2.5 | 3.3 | 3.6 | V | |
| Transmitting current |
560 |
600 | 660 | mA | 30dBm(1W) |
| Receiving current | 20 | 21 | 23 | mA | |
| Sleep current | 4 | 5 | 6 | μA | |
| Operating temperature | -40 | 20 | +85 | ℃ | |
| Operating humidity | 10 | 60 | 90 | % | |
| Storage temperature | -40 | 20 | +125 | ℃ |
Additional information
| Brand Name | EBYTE |
|---|---|
| Origin | CN(Origin) |
| Condition | New |
| Type | Drive IC |
| Model Number | E32-868T30S |
| Size | 25 * 40.3 mm |
| Working frequency | 868MHz |
| Distance | 8000m |
| Transmitting power | SMA-K |
| Antenna Type | IPEX/stamp hole |
| Interface | UART |
| Voltage | 5.0 V( 3.3 -5.2 V) |
